When installing the fixed base force sensor, the sensor is placed in three fixed stop posts. We require to use in the temperature range is not big occasions, its advantage is to improve the stability of the scale body, and convenient installation and debugging. Attention should also be paid to the installation of the weighing load cell:

1. In order to prevent large current from flowing through the transducer, a short circuit sheet should be installed between the sensors to prevent the accidental large current flow and burn it out. Even so, when high current welding is required, it is best to remove the pressure sensor and install the weight sensor after the operation is complete.

2. Ball bearings and other moving parts should keep sliding freely, without jamming, corrosion and other phenomena.

3. The indenter shall be made of 20mm thick chromium steel. The bottom surface of the indenter should be machined into an arc, the radius of which should be more than 3 times the radius of the sensor dome, and heat treatment should be carried out to increase the hardness of the indenter. The fixed plate shall be made of 45 steel, the thickness of which shall not be less than 20mm, and the levelness of installation shall not exceed ±0.5°.
